Two or three independently driven agitators working in tandem — LZ dual-shaft and SZ triple-shaft configurations. Built for very high-viscosity products up to 750,000 cps. Open, vacuum, and hydraulic lift variants.
Every machine in this family is built in our own factory, hydrostatic-tested, and video-inspected before shipment. Engineers reply to inquiries within 24 hours.
Capacity: 100L – 1000L
Open-top dual-shaft mixer without hydraulics. Low-speed anchor + high-speed disperser. Up to 500,000 cps.
Capacity: 100L – 1500L
Open-top triple-shaft mixer without hydraulics. Anchor + disperser + scraper. Up to 750,000 cps.
Capacity: 100L – 1000L
Vacuum-sealed dual-shaft mixer without hydraulic lift. For air-sensitive formulations.
Capacity: 100L – 1500L
Vacuum-sealed triple-shaft mixer without hydraulic lift.
Capacity: 100L – 1000L
Vacuum dual-shaft with hydraulic lid lift — the production-scale workhorse.
Capacity: 100L – 1500L
Vacuum triple-shaft with hydraulic lid lift — for the highest viscosity production runs.
Indicative specs. Final spec sheet issued with your formal quotation.
| Capacity range | 100L – 1500L |
|---|---|
| Shaft configurations | Dual (LZ) or Triple (SZ) |
| Anchor speed | 10–60 rpm |
| Disperser speed | 300–1500 rpm |
| Viscosity range | Up to 750,000 cps |
| Material (contact) | SS316L |
| Heating | Jacketed |
| Configurations | Open / Vacuum / Vacuum with Hydraulic Lift |
100L – 1000L · Disperser 4 – 22 kW homogenizer
100L – 1000L · Disperser 4 – 22 kW homogenizer
100L – 1000L · Disperser 4 – 22 kW homogenizer
100L – 1500L · Disperser 5.5 – 30 kW homogenizer
100L – 1500L · Disperser 5.5 – 30 kW homogenizer
100L – 1500L · Disperser 5.5 – 30 kW homogenizer
